THERMAL MANAGEMENT
Exhaust Fans for RFM2 Cabinets
| PART NUMBER | FANS | AIRFLOW | PLUG |
|---|---|---|---|
| RFM2-2-FAN-CAB | 2 | 220 CFM | 5-15P |
| RFM2-4-FAN-CAB | 4 | 440 CFM | 5-15P |
This item is for RFM2 Cabinets only.
RFM2 4” Exhaust Fans:
- 115VAC 50/60HZ 24/22W (Standard per each unit)
(230VAC 50/60HZ available upon request)
- Plug Type: 5-15P
- Fits RFM2 Cabinets only (36”, 31.5″, 30” & 24” Width Cabinets)
- Total Air Flow: 220 CFM (2-Fan), 440CFM (4-Fan)
Exhaust Fans for Wall Mount Cabinets
| PART NUMBER | FANS | AIRFLOW | PLUG |
|---|---|---|---|
| RFM-1-FAN | 1 | 110 CFM | 5-15P |
| RFM-2-FAN | 2 | 220 CFM | 5-15P |
RFM 4” Exhaust Fans:
- 115VAC 50/60HZ 24/22W (Standard per each unit)
(230VAC 50/60HZ available upon request)
- Plug Type: 5-15P
- Fits RFM Wall Mount Cabinets only ( 30”& 24” Width Cabinets,
and Low Profile Cabinets)
- Total Air Flow: 110 CFM (1-Fan), 220CFM (2-Fan)
Blank Filler Plates - Composite Material
| PART NUMBER | RU's | MOUNTING | QTY |
|---|---|---|---|
| RFM-BPTL-19-1U | 1U | 19" EIA | Pack of 10 |
| RFM-BPTL-19-2U | 2U | 19" EIA | Pack of 10 |
- Composite material, tool-less installation
- Supplied in contractor packs: qty 10
Blank Filler Plates - Steel Material
| PART NUMBER | RU's | MOUNTING |
|---|---|---|
| RFM-BP19-1U | 1U | 19" EIA |
| RFM-BP19-2U | 2U | 19" EIA |
| RFM-BP19-4U | 4U | 19" EIA |
| RFM-BP19-9U | 9U | 19" EIA |
- Steel material, black
- mounting screws included
Air Dam Kit
| 36" WIDE CABINET | 31.5" WIDE CABINET | 30" WIDE CABINET | 24" WIDE CABINET | RU's |
|---|---|---|---|---|
| RFM2-ADK-3152-B | 52U | |||
| RFM2-ADK-3148-B | 48U | |||
| RFM2-ADK-3145-B | 45U | |||
| RFM2-ADK-3142-B | 42U | |||
| RFM2-ADK-3130-B | 30U | |||
| RFM2-ADK-3117-B | 17U | |||
| Brush Covers | QTY | FITS |
|---|---|---|
| RFM2-ADBK | 8 | RFM2-ADK-30xx-BRFM2-ADK-36xx-B |
- The Air Dam Kit attaches to the front mounting rails, providing a complete seal around
mounted equipment, ensuring complete airflow isolation and eliminating bypass airflow.
- The Air Dam Kit also provides seals above and below mounted equipment.
- Set of 8 brush covers that conceal cable opening in the equipment mounting rails to block airflow around equipment.
